Key features
1)16x2 LCD Display
2. DSP Based architecture and Algorithms
for operation and protection
3. The unit is password protected
4. Front panel LED indication for Power,
Motor-ON/OFF, AUTO/MANUAL,
TRIP status, Communication LED.
5. Front panel tactile switches for selection
of Motor ON/OFF (DEC KEY),
AUTO/MANUAL (INC KEY)
6. Contactor for Motor-ON/OFF
7. Exclusive Contactors for Motor ON/OFF, Motor TRIP &
AUTO/MANUAL
(for BMS purpose)
8. DI (Potential Free Digital Input) for Motor ON/OFF in Auto mode.
9. If Trip occurs then Buzzer gets ON until the fault gets accepted
manually
10. Auxiliary Supply is 230V AC @ 50 Hz
11. Protection Functions such as
1. Overload Protection
2. Under Load Protection
3. Over Voltage Protection
4. Under Voltage Protection
